Electronic Marker Locator 1420X: A Smarter Solution for Underground Utility Identification

Electronic Marker Locator 1420X

The Electronic Marker Locator 1420X is designed to detect, locate, read, and manage Electronic Route Markers (ERMs) installed underground for utility identification and network route mapping. It helps field teams accurately identify buried utility markers and access stored information for efficient maintenance and troubleshooting.

Key Features and Functions

• Locate ERM: Detect and locate buried Electronic Route Markers.
• Read ERM: Retrieve the information stored in the marker.
• Write ERM: Program and store relevant utility or network information in the marker.
• Rewrite ERM: Update or modify previously stored information.
• Permanently Lock ERM: Permanently lock the marker to prevent further modification of stored data.
• Depth Check: Measure the approximate underground depth of the Electronic Route Marker.
• Rechargeable Battery: Supports convenient and cost-effective field operation.
• Type-C Charging Adapter: Provides convenient charging through a Type-C adapter.
• Built-in GPS: Supports location identification and helps record marker positions for network mapping and maintenance.

RFID Electronic Route Marker (ERM)

 The RFID Electronic Route Marker is designed for underground utility identification and route marking. It enables utility teams to identify buried infrastructure using a compatible electronic marker locator. Markers are available in different detection ranges to meet various installation depths and field requirements.

Available Detection Ranges:

• Short Range :            Up to 3 ft
• Medium Range:       Up to 5 ft
• Long Range:             Up to 9 ft

Note: Actual detection range may vary depending on installation depth, soil conditions, marker orientation, and locator compatibility.

Utility Identification by Colour

Different marker colours are used to identify specific underground utilities, helping field personnel distinguish between utility networks during installation, inspection, and maintenance.

• Orange: Telecommunications
• Red:       Electricity
• Yellow:  Gas
• Blue:      Water
• Green:   Wastewater / Sewerage

Key Benefits

• Efficient identification and location of underground utilities.
• Digital storage and management of utility information.
• Reduced time spent locating buried network infrastructure.
• Improved accuracy in utility maintenance and troubleshooting.
• Better support for underground network mapping and asset management.
• Colour-coded identification for easy differentiation of utility types.

Applications

The Electronic Marker Locator 1420X and RFID Electronic Route Markers can be used in telecommunications networks, electrical distribution systems, gas pipelines, water supply networks, and wastewater infrastructure, subject to compatibility with the relevant marker specifications.

Conclusion: The Electronic Marker Locator 1420X, combined with RFID Electronic Route Markers, provides a practical solution for underground utility identification, marker data management, depth checking, and field maintenance activities.
